Acson AWM 25GR

153
Exploded View and Part List AWM-G-2009
Note: All exploded view and part list are subjected to change by the manufacturer without prior notice
OUTDOOR UNIT
MODEL: A5LC 20CR
No Description Part Number
1 Assy. Base Pan R50014078281
2 Assy. Outdoor Coil R50024075143
3 Bracket, Fan Motor R01014070601
4 Fan Motor R03039024539
5 Fan Propeller R03019023393
6 Assy. Valve Bracket R50014078280
7 Assy. 3 Ways Valve 1/2”
A5LC 20CR R50059030471
8 Assy. 2 Ways Valve 1/4”
A5LC 20CR R50059030628
9 Compressor R04019020625
10 Front Panel, Left R01014070597Y
11 Service Panel R01014070598
12 Terminal Cover Panel R01014070838
No Description Part Number
13 Assy. Control Panel R50044086136
14 Top Panel R01014070596Y
15 Assy. Front Grille R50124093631
16 Plastic Handle R12014057948
17 Assy. Valve Cover R50124072885
18 Assy. Cap Tube R50024081904
19 Partition R01014070603
Parts Not in Diagram
Capacitor, Fan Motor R04029026759
Capacitor, Compressor R04029026779
Valve, Rev 4 Way R05019016937
Defrost Thermistor R50134039416
Back Panel, Right R01014070599
