Acson AWM 25GR

155
Exploded View and Part List AWM-G-2009
Note: All exploded view and part list are subjected to change by the manufacturer without prior notice
OUTDOOR UNIT
MODEL: A5LC 25/28C
No Description Part Number
1 Assy. Base Pan
A5LC 25C R50014078281
A5LC 28C R50014073884
2 Assy. Outdoor Coil R50024079238
3 Bracket, Fan Motor R01014070948
4 Fan Motor
A5LC 25C R03039023391
A5LC 28C R03039024538
5 Fan Propeller R03019023393
6 Assy. Valve Bracket
A5LC 25C R50014078321
A5LC 28C R50014080371
7 Assy. 3 Ways Valve 5/8” R50059030488
8 Assy. 2 Ways Valve 1/4”
A5LC 25C R50059030628
Assy. 3 Ways Valve 3/8”
A5LC 28C R50059024820
9 Compressor
A5LC 25C R04019021361
A5LC 28C R04019020449
10 Front Panel, Left R01014070947Y
No Description Part Number
11 Service Panel R01014070949Y
12 Terminal Cover Panel R01014070838
13 Assy. Control Panel
A5LC 25C R50044086076
A5LC 28C R50044086138
14 Top Panel R01014070596Y
15 Assy. Front Grille R50124093631
16 Plastic Handle R12014057948
17 Assy. Valve Cover R50124073905
18 Assy. Cap Tube
A5LC 25C R50024081916
A5LC 28C R50024079593
19 Partition R01014070951Y
Parts Not in Diagram
Capacitor, Fan Motor
A5LC 25C R04029026759
A5LC 28C R04029026966
Capacitor, Compressor
A5LC 25C R04029026779
A5LC 28C R04029026778
Back Panel, Right R01014070950Y
