AWM-G-2009 Exploded View and Part List
Note: All exploded view and part list are subjected to change by the manufacturer without prior notice
OUTDOOR UNIT
MODEL: A5LC 25/28CR
No Description Part Number
1 Assy. Base Pan
A5LC 25CR R50014078281
A5LC 28CR R50014073884
2 Assy. Outdoor Coil R50024075147
3 Bracket, Fan Motor R01014070948
4 Fan Motor
A5LC 25CR R03039023391
A5LC 28CR R03039024538
5 Fan Propeller R03019023393
6 Assy. Valve Bracket
A5LC 25CR R50014078321
A5LC 28CR R50014080371
7 Assy. 3 Ways Valve 5/8” R50059030488
8 Assy. 2 Ways Valve 1/4”
A5LC 25CR R50059030628
Assy. 3 Ways Valve 3/8”
A5LC 28C R50059024820
9 Compressor
A5LC 25CR R04019021361
A5LC 28CR R04019020449
10 Front Panel, Left R01014070947Y
11 Service Panel R01014070949Y
No Description Part Number
12 Terminal Cover Panel R01014070838
13 Assy. Control Panel
A5LC 25CR R50044086136
A5LC 28CR R50044086140
14 Top Panel R01014070596Y
15 Assy. Front Grille R50124093631
16 Plastic Handle R12014057948
17 Assy. Valve Cover R50124073905
18 Assy. Cap Tube
A5LC 25CR R50024081899
A5LC 28CR R50024080312
19 Partition R01014070951Y
Parts Not in Diagram
Capacitor, Fan Motor
A5LC 25CR R04029026759
A5LC 28CR R04029026966
Capacitor, Compressor
A5LC 25CR R04029026779
A5LC 28CR R04029026778
Back Panel, Right R01014070950Y
Valve, Rev 4 Way R05019016937
