AWM-G-2009 Electrical Data
Electrical Data - Cooling Only (R410A)
MODEL
INDOOR UNIT A5WM 07G A5WM 09G
OUTDOOR UNIT A5LC 07C A5LC 10C
INDOOR MOTOR
INSULATION GRADE CLASS E CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
RATED INPUT POWER W 24 24
RATED RUNNING CURRENT A 0.11 0.11
MOTOR OUTPUT W 88
POLES 44
OUTDOOR MOTOR
INSULATION GRADE CLASS B CLASS B
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
RATED INPUT POWER W 40 52
RATED RUNNING CURRENT A 0.18 0.23
MOTOR OUTPUT W 20 35
POLES 66
COMPRESSOR
INSULATION GRADE CLASS E CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
CAPACITOR mF 15.0 25.0
RATED INPUT POWER W 556 789
RATED RUNNING CURRENT A 2.60 3.60
LOCKED ROTOR AMP. A 12 19
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
Electrical Data - Heat Pump (R410A)
MODEL
INDOOR UNIT A5WM 07GR A5WM 09GR
OUTDOOR UNIT A5LC 07CR A5LC 10CR
INDOOR MOTOR
INSULATION GRADE CLASS E CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
RATED INPUT POWER W 24 24
RATED RUNNING CURRENT A 0.11 0.11
MOTOR OUTPUT W 88
POLES 44
OUTDOOR MOTOR
INSULATION GRADE CLASS B CLASS B
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
RATED INPUT POWER W 40 52
RATED RUNNING CURRENT A 0.18 0.23
MOTOR OUTPUT W 20 20
POLES 66
COMPRESSOR
INSULATION GRADE CLASS E CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
CAPACITOR mF 15.0 25.0
RATED INPUT POWER (COOLING) W 616 784
RATED INPUT POWER (HEATING) W 486 669
RATED RUNNING CURRENT (COOLING) A 2.80 3.60
RATED RUNNING CURRENT (HEATING) A 2.40 3.10
LOCKED ROTOR AMP. A 12 19
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.

Acson AWM 301 Specifications
