Acson AWM 301 Technical Manual

105
Electrical Data AWM-G-2009
Electrical Data - Cooling Only (R410A)
MODEL
INDOOR UNIT A5WM 10G A5WM 15G
OUTDOOR UNIT A5LC 10C A5LC 15C
INDOOR MOTOR
INSULATION GRADE CLASS E CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
RATED INPUT POWER W 26 29
RATED RUNNING CURRENT A 0.11 0.13
MOTOR OUTPUT W 913
POLES 44
OUTDOOR MOTOR
INSULATION GRADE CLASS B CLASS B
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
RATED INPUT POWER W 52 59
RATED RUNNING CURRENT A 0.23 0.26
MOTOR OUTPUT W 35 35
POLES 66
COMPRESSOR
INSULATION GRADE CLASS E CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
CAPACITOR mF 25.0 30.0
RATED INPUT POWER W 789 1142
RATED RUNNING CURRENT A 3.60 5.10
LOCKED ROTOR AMP. A 19 24
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
Electrical Data - Heat Pump (R410A)
MODEL
INDOOR UNIT A5WM 10GR A5WM 15GR
OUTDOOR UNIT A5LC 10CR A5LC 15CR
INDOOR MOTOR
INSULATION GRADE CLASS E CLASS B
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
RATED INPUT POWER W 26 29
RATED RUNNING CURRENT A 0.11 0.13
MOTOR OUTPUT W 913
POLES 44
OUTDOOR MOTOR
INSULATION GRADE CLASS B CLASS B
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
RATED INPUT POWER W 52 59
RATED RUNNING CURRENT A 0.23 0.26
MOTOR OUTPUT W 35 35
POLES 66
COMPRESSOR
INSULATION GRADE CLASS E CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
CAPACITOR mF 25.0 35.0
RATED INPUT POWER (COOLING) W 789 1142
RATED INPUT POWER (HEATING) W 669 992
RATED RUNNING CURRENT (COOLING) A 4.00 5.23
RATED RUNNING CURRENT (HEATING) A 3.00 4.59
LOCKED ROTOR AMP. A 19 24
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
