Exploded View and Part List AWM-G-2009
Note: All exploded view and part list are subjected to change by the manufacturer without prior notice
INDOOR UNIT
MODEL: AWM 301, A5WM 311
No
Description Part Number
1 Assy. Installation Bracket R50014050721
2 Assy. Chassis R50124050703
3 Piping Clamp R07014024546
4 Fan Bush Bracket R12014050709
5 Cross Flow Fan R03029013842
6 Fan Bush R11019013841
7 Assy. Coil
AWM 301 R50024050710
A5WM 311 R50024084359
8 Service Panel R12014050685
9 Control Module R04084090222
10 Fan Motor R03034052105
11 Assy. Control Box R50044090264
12 LED Light Bracket R12014050679
13 Handset, Wireless G18 R04084103441
No
Description Part Number
14 Control Box Cover R12014050681
15 Assy. Drain Hose R10024015319
16 Air Swing Motor R03039007088
17 Air Louver R12014050717
18 Assy. Air Discharge Housing R50124050712
19 Coil Sensor Clip R07054021183
20 Assy. Front Cover R50124050723
21 Saranet Filter R12014050726
22 Thermistor Holder
AWM 301 R12014000432
A5WM 311 R12014016707
Parts Not in Diagram
Assy. Orifi ce Pipe
AWM 301 R50024063203
INDOOR UNIT
MODEL: AWM 301R, A5WM 301R
No Description Part Number
1 Assy. Installation Bracket R50014050721
2 Assy. Chassis R50124050703
3 Piping Clamp R07014024546
4 Fan Bush Bracket R12014050709
5 Cross Flow Fan R03029013842
6 Fan Bush R11019013841
7 Assy. Coil
AWM 301R R50024050710
A5WM 301R R50024084359
8 Service Panel R12014050685
9 Control Module R04084090162
10 Fan Motor R03034052105
11 Assy. Control Box R50044090014
No Description Part Number
12 LED Light Bracket R12014050679
13 Handset, Wireless G18 R04084103443
14 Control Box Cover R12014050681
15 Assy. Drain Hose R10024015319
16 Air Swing Motor R03039007088
17 Air Louver R12014050717
18 Assy. Air Discharge Housing R50124050712
19 Coil Sensor Clip R07054021183
20 Assy. Front Cover R50124050723
21 Saranet Filter R12014050726
22 Thermistor Holder
AWM 301R R12014000432
A5WM 301R R12014016707
To Next Page
