Acson AWM 301 Technical Manual

140
AWM-G-2009 Exploded View and Part List
Note: All exploded view and part list are subjected to change by the manufacturer without prior notice
OUTDOOR UNIT
MODEL: ALC 10/15C
No Description Part Number
1 Assy. Base Pan R50014051158
2 Assy. Outdoor Coil
ALC 10C R50024085384
ALC 15C R50024087838
3 Compressor
ALC 10C R04019019550
ALC 15C R04019027709
4 Valve Bracket R01014051164
5 Assy. Partition R50064055063
6 Assy. Cap Tube
ALC 10C R50024085382
ALC 15C R50024087757
7 Left Panel R01014051166Y
8 Right Panel R01014051167Y
9 Bracket, Fan Motor R01014051162Y
10 Fan Motor
ALC 10C R03039016104
ALC 15C R03039015323
No Description Part Number
11 Assy. Control Panel R50044086056
12 Assy. Valve Cover R50124051173
13 Top/Front Panel R01014051171Y
14 Assy. Front Grille R50124093630
15 Fan Propeller R03019015339
Parts Not in Diagram
Capacitor, Fan Motor R04029026755
Capacitor, Compressor R04029026775
Assy. Flare Valve 2 Ways
1/4”
ALC 10/15C R50059029814
Assy. Flare Valve 3 Ways
1/2”
ALC 15C R50059029816
Assy. Flare Valve 3 Ways
3/8”
ALC 10C R50059029815
