Acson AWM 301 Technical Manual

141
Exploded View and Part List AWM-G-2009
Note: All exploded view and part list are subjected to change by the manufacturer without prior notice
OUTDOOR UNIT
MODEL: ALC 10/15CR
No Description Part Number
1 Assy. Base Pan R50014051158
2 Assy. Outdoor Coil
ALC 10CR R50024085384
ALC 15CR R50024060071
3 Compressor
ALC 10CR R04019019550
ALC 15CR R04019019125
4 Valve Bracket R01014051164
5 Assy. Partition R50064055063
6 Assy. Cap Tube
ALC 10CR R50024085462
ALC 15CR R50024071222
7 Left Panel R01014051166Y
8 Right Panel R01014051167Y
9 Bracket, Fan Motor R01014051162Y
10 Fan Motor
ALC 10CR R03039016104
ALC 15CR R03039015323
11 Assy. Control Panel
ALC 10CR R50044086062
ALC 15CR R50044086063
No Description Part Number
12 Assy. Valve Cover R50124051173
13 Top/Front Panel R01014051171Y
14 Assy. Front Grille R50124093630
15 Fan Propeller R03019015339
Parts Not in Diagram
Capacitor, Fan Motor R04029026755
Capacitor, Compressor
ALC 10CR R04029026775
ALC 15CR R04029026776
Assy. Flare Valve 2 Ways
1/4”
R50059029814
Assy. Flare Valve 3 Ways
3/8”
ALC 10CR R50059029815
Assy. Flare Valve 3 Ways
1/2”
ALC 15CR R50059029816
Valve, Rev 4 Way R05019004157
