HEATING MODE
R410A Models
(Heatpump)
MODEL : A5WM 20GR / A5LC 20CR
COOLING MODE
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
5.147 3.507 4.918 3.236 4.654 3.002 4.390 2.769 4.126 2.535 3.809 2.255
16
5.349 3.308 5.102 3.073 4.838 2.858 4.574 2.642 4.310 2.427 3.992 2.168
16
5.349 4.197 5.102 3.963 4.838 3.747 4.574 3.532 4.310 3.316 3.992 3.057
17
5.551 3.997 5.287 3.800 5.022 3.602 4.758 3.405 4.493 3.208 4.176 2.971
18
5.769 3.780 5.498 3.608 5.227 3.435 4.956 3.263 4.685 3.091 4.360 2.884
19
5.994 3.549 5.755 3.330 5.515 3.112 5.276 2.894 4.943 2.850 4.543 2.798
20
6.201 3.333 5.901 3.151 5.600 2.968 5.300 2.785 4.999 2.603 4.639 2.383
18
5.769 4.669 5.498 4.497 5.227 4.325 4.956 4.152 4.685 3.980 4.360 3.774
19
5.994 4.438 5.755 4.220 5.515 4.001 5.276 3.783 4.943 3.739 4.543 3.687
20
6.201 4.223 5.901 4.040 5.600 3.857 5.300 3.675 4.999 3.492 4.639 3.273
21
6.416 3.993 6.093 3.775 5.769 3.557 5.446 3.338 5.122 3.120 4.734 2.858
22
6.631 3.764 6.284 3.510 5.938 3.256 5.592 3.002 5.245 2.748 4.829 2.444
23
6.845 3.534 6.476 3.245 6.107 2.956 5.737 2.666 5.368 2.377 4.925 2.029
24
7.060 3.305 6.668 2.980 6.276 2.655 5.883 2.330 5.491 2.005 5.020 1.615
20
6.201 4.667 5.901 4.485 5.600 4.302 5.300 4.119 4.999 3.936 4.639 3.717
21
6.416 4.438 6.093 4.220 5.769 4.001 5.446 3.783 5.122 3.565 4.734 3.303
22
6.631 4.209 6.284 3.955 5.938 3.701 5.592 3.447 5.245 3.193 4.829 2.888
23
6.845 3.979 6.476 3.690 6.107 3.400 5.737 3.111 5.368 2.821 4.925 2.474
24
7.060 3.750 6.668 3.425 6.276 3.100 5.883 2.775 5.491 2.450 5.020 2.060
20
24
28
30
ID DB°C ID WB°C
Outdoor DB°C
20 25 30 35 40 46
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15 3.189 3.189 3.610 3.610 3.750 3.750 5.291 5.291 6.132 6.132 6.553 6.553 6.973 6.973
17
3.106 3.106 3.514 3.514 3.677 3.677 5.285 5.285 6.106 6.106 6.535 6.535 6.964 6.964
19 3.022 3.022 3.418 3.418 3.605 3.605 5.279 5.279 6.080 6.080 6.517 6.517 6.954 6.954
21
2.938 2.938 3.340 3.340 3.532 3.532 5.241 5.241 6.055 6.055 6.500 6.500 6.945 6.945
23 2.855 2.855 3.279 3.279 3.459 3.459 5.173 5.173 6.029 6.029 6.482 6.482 6.935 6.935
25
2.771 2.771 3.218 3.218 3.387 3.387 5.105 5.105 6.003 6.003 6.464 6.464 6.926 6.926
27 2.688 2.688 3.157 3.157 3.314 3.314 5.037 5.037 5.977 5.977 6.447 6.447 6.917 6.917
FROST REGION
ID DB°C
Outdoor WB°C
-9 -6 -5 6 12 15 18
