HEATING MODE
R22 Models
(Heatpump)
MODEL : AWM 09GR / ALC 09CR
COOLING MODE
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
3.163 2.063 2.934 1.852 2.705 1.641 2.476 1.430 2.247 1.219 1.972 0.966
16
3.205 1.896 2.978 1.704 2.752 1.513 2.525 1.322 2.299 1.130 2.027 0.901
16
3.205 2.420 2.978 2.228 2.752 2.037 2.525 1.846 2.299 1.654 2.027 1.425
17
3.246 2.252 3.022 2.081 2.798 1.909 2.574 1.737 2.351 1.565 2.082 1.359
18
3.287 2.085 3.066 1.933 2.845 1.781 2.624 1.629 2.402 1.476 2.137 1.294
19
3.329 1.918 3.110 1.785 2.891 1.653 2.673 1.520 2.454 1.388 2.192 1.228
20
3.370 1.750 3.158 1.637 2.947 1.524 2.735 1.410 2.523 1.297 2.268 1.161
18
3.287 2.609 3.066 2.457 2.845 2.305 2.624 2.153 2.402 2.001 2.137 1.818
19
3.329 2.442 3.110 2.309 2.891 2.177 2.673 2.044 2.454 1.912 2.192 1.752
20
3.370 2.274 3.158 2.161 2.947 2.048 2.735 1.934 2.523 1.821 2.268 1.685
21
3.413 2.107 3.210 2.012 3.007 1.918 2.805 1.823 2.602 1.729 2.359 1.615
22
3.455 1.939 3.261 1.864 3.068 1.788 2.875 1.713 2.681 1.637 2.449 1.546
23
3.497 1.772 3.313 1.715 3.129 1.658 2.945 1.602 2.761 1.545 2.540 1.477
24
3.539 1.605 3.364 1.567 3.190 1.529 3.015 1.491 2.840 1.453 2.631 1.408
20
3.370 2.536 3.158 2.423 2.947 2.310 2.735 2.196 2.523 2.083 2.268 1.947
21
3.413 2.369 3.210 2.274 3.007 2.180 2.805 2.085 2.602 1.991 2.359 1.877
22
3.455 2.201 3.261 2.126 3.068 2.050 2.875 1.975 2.681 1.899 2.449 1.808
23
3.497 2.034 3.313 1.977 3.129 1.921 2.945 1.864 2.761 1.807 2.540 1.739
24
3.539 1.867 3.364 1.829 3.190 1.791 3.015 1.753 2.840 1.715 2.631 1.670
ID DB°C ID WB°C
Outdoor DB°C
20 25 30 35 40 46
20
24
28
30
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15 1.181 1.181 1.471 1.471 1.568 1.568 2.630 2.630 3.210 3.210 3.500 3.500 3.790 3.790
17
1.154 1.154 1.442 1.442 1.538 1.538 2.591 2.591 3.123 3.123 3.402 3.402 3.682 3.682
19 1.126 1.126 1.413 1.413 1.508 1.508 2.552 2.552 3.035 3.035 3.305 3.305 3.574 3.574
21
1.098 1.098 1.383 1.383 1.479 1.479 2.512 2.512 2.948 2.948 3.207 3.207 3.466 3.466
23 1.094 1.094 1.360 1.360 1.449 1.449 2.416 2.416 2.860 2.860 3.110 3.110 3.359 3.359
25
1.090 1.090 1.337 1.337 1.419 1.419 2.320 2.320 2.773 2.773 3.012 3.012 3.251 3.251
27 1.086 1.086 1.314 1.314 1.389 1.389 2.224 2.224 2.686 2.686 2.914 2.914 3.143 3.143
ID DB°C
Outdoor WB°C
-9 -6 -5 6 12 15
FROST REGION
18
