R410A Models
(Cooling only)
MODEL : A5WM 20G / A5LC 20C (3 PHASE)
MODEL : A5WM 25G/ A5LC 25C (3 PHASE)
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
5.206 3.550 4.976 3.280 4.711 3.049 4.447 2.818 4.182 2.587 3.864 2.310
16
5.402 3.346 5.156 3.114 4.892 2.902 4.628 2.689 4.365 2.477 4.049 2.222
16
5.402 4.235 5.156 4.003 4.892 3.791 4.628 3.579 4.365 3.366 4.049 3.112
17
5.597 4.031 5.335 3.838 5.073 3.644 4.810 3.450 4.548 3.256 4.233 3.024
18
5.809 3.810 5.541 3.642 5.274 3.474 5.006 3.306 4.739 3.138 4.417 2.936
19
6.025 3.571 5.775 3.345 5.526 3.120 5.276 2.894 4.970 2.873 4.602 2.848
20
6.229 3.353 5.935 3.175 5.640 2.997 5.346 2.819 5.052 2.641 4.699 2.428
18
5.809 4.699 5.541 4.531 5.274 4.363 5.006 4.195 4.739 4.027 4.417 3.825
19
6.025 4.460 5.775 4.235 5.526 4.009 5.276 3.783 4.970 3.762 4.602 3.737
20
6.229 4.243 5.935 4.065 5.640 3.887 5.346 3.709 5.052 3.531 4.699 3.317
21
6.437 4.008 6.121 3.795 5.806 3.581 5.490 3.367 5.174 3.153 4.795 2.897
22
6.646 3.774 6.308 3.525 5.971 3.275 5.634 3.025 5.297 2.776 4.892 2.476
23
6.854 3.540 6.495 3.255 6.136 2.969 5.778 2.684 5.419 2.398 4.988 2.056
24
7.062 3.306 6.682 2.985 6.302 2.663 5.922 2.342 5.541 2.021 5.085 1.635
20
6.229 4.687 5.935 4.509 5.640 4.331 5.346 4.153 5.052 3.975 4.699 3.762
21
6.437 4.453 6.121 4.239 5.806 4.025 5.490 3.812 5.174 3.598 4.795 3.341
22
6.646 4.219 6.308 3.969 5.971 3.720 5.634 3.470 5.297 3.220 4.892 2.921
23
6.854 3.985 6.495 3.699 6.136 3.414 5.778 3.128 5.419 2.843 4.988 2.500
24
7.062 3.750 6.682 3.429 6.302 3.108 5.922 2.787 5.541 2.465 5.085 2.080
ID DB°C ID WB°C
Outdoor DB°C
20 25 30 35 40 46
20
24
28
30
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
6.762 4.377 6.391 3.963 5.957 3.582 5.523 3.202 5.089 2.821 4.568 2.365
16
6.971 4.123 6.585 3.751 6.168 3.397 5.751 3.042 5.333 2.687 4.832 2.261
16
6.971 5.382 6.585 5.010 6.168 4.655 5.751 4.301 5.333 3.946 4.832 3.520
17
7.180 5.128 6.779 4.799 6.379 4.470 5.978 4.140 5.577 3.811 5.097 3.416
18
7.418 4.859 7.023 4.562 6.627 4.264 6.231 3.967 5.836 3.669 5.361 3.312
19
7.663 4.591 7.306 4.332 6.949 4.074 6.592 3.816 6.153 3.539 5.626 3.208
20
7.889 4.305 7.476 3.999 7.064 3.692 6.651 3.386 6.239 3.079 5.744 2.712
18
7.418 6.118 7.023 5.820 6.627 5.523 6.231 5.225 5.836 4.928 5.361 4.571
19
7.663 5.850 7.306 5.591 6.949 5.333 6.592 5.074 6.153 4.798 5.626 4.467
20
7.889 5.564 7.476 5.258 7.064 4.951 6.651 4.645 6.239 4.338 5.744 3.971
21
8.121 5.280 7.687 4.933 7.252 4.586 6.818 4.238 6.383 3.891 5.862 3.474
22
8.354 4.996 7.898 4.608 7.441 4.220 6.984 3.831 6.528 3.443 5.980 2.977
23
8.587 4.712 8.108 4.283 7.630 3.854 7.151 3.425 6.672 2.996 6.098 2.481
24
8.819 4.428 8.319 3.958 7.818 3.488 7.318 3.018 6.817 2.548 6.216 1.984
20
7.889 6.194 7.476 5.887 7.064 5.581 6.651 5.274 6.239 4.968 5.744 4.600
21
8.121 5.910 7.687 5.562 7.252 5.215 6.818 4.868 6.383 4.520 5.862 4.103
22
8.354 5.626 7.898 5.238 7.441 4.849 6.984 4.461 6.528 4.073 5.980 3.607
23
8.587 5.342 8.108 4.913 7.630 4.483 7.151 4.054 6.672 3.625 6.098 3.110
24
8.819 5.058 8.319 4.588 7.818 4.118 7.318 3.648 6.817 3.178 6.216 2.613
ID DB°C ID WB°C
Outdoor DB°C
20 25 30 35 40 46
20
24
28
30
