24
Application Information
Cable Size
Model Unit AWM / ACK / ACM
Power supply cable size* mm2 1.5
Number of wire 3
Recommended fuse* A 2
Model Unit ACC10CW ACC15CW ACC20CW ACC25CW
Power supply cable size* mm2 1.5 1.5 1.5 1.5
Number of wire 3 3 3 3
Recommended fuse* A 1 1 1 2
Model Unit ACC30CW ACC38/40/50/
60CW
ACC06/09/15FWD ACC18/24FWD
Power supply cable size* mm2 1.5 1.5 1.5 1.5
Number of wire 3 3 5 5
Recommended fuse* A 3 5 1 2
Model Unit ACC30FWD ACC-GW ADB75/100BW ADB120/150BW
Power supply cable size* mm2 1.5 1.0 1.5 1.5
Number of wire 5 5 3 4
Recommended fuse* A 3 6 10 10
Important: * These values are for information only. They should be checked and selected to comply local
or national codes and regulations. They are also subjected to the type of installation and size of
conductor
