INDOOR UNIT
MODEL : AWM 20F / 20FR / 25F / 25FR
OUTDOOR UNIT
MODEL : ALC 20B / 20BR / 25B / 25BR / 30B / 30BR
A4LC 20B / 20BR / 25B / 25BR
39
293.9
133.9
0.0
0.0
430.0
911.7
430.0
530.0
TOP VIEW
FRONT VIEW
SIDE VIEW
INSTALLATION PLATE
Note : Dimension in mm
Note : Dimension in mm
