Engineering & Physical Data AWM-J-2010
General Data - Cooling Only (R22)
MODEL
INDOOR UNIT AWM20J AWM25J
OUTDOOR UNIT ALC20C ALC25C
NOMINAL CAPACITY
Btu/h 19500 24000
W 5720 7030
NOMINAL TOTAL INPUT POWER W 1850 2530
NOMINAL RUNNING CURRENT A 8.21 11.30
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
EER W/W 3.09 2.78
REFRIGERANT TYPE R22 R22
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE OUTDOOR CAP. TUBE
INDOOR UNIT
CONTROL
AIR DISCHARGE
AUTO LOUVER (UP & DOWN) &
GRILLE (LEFT & RIGHT)
AUTO LOUVER (UP & DOWN) &
GRILLE (LEFT & RIGHT)
OPERATION LCD REMOTE CONTROL LCD REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM 252 / 536 290 / 616
MEDIUM l/s / CFM 225 / 478 253 / 537
LOW l/s / CFM 200 / 424 223 / 474
SOUND PRESSURE LEVEL (H/M/L) dBA 42 / 39 / 36 43 / 39 / 37
UNIT DIMENSION
HEIGHT mm/in 310 / 12.2 310 / 12.2
WIDTH mm/in 1065 / 41.9 1065 / 41.9
DEPTH mm/in 224 / 8.8 224 / 8.8
PACKING DIMENSION
HEIGHT mm/in 370 / 14.6 370 / 14.6
WIDTH mm/in 1121 / 44.1 1121 / 44.1
DEPTH mm/in 285 / 11.2 285 / 11.2
UNIT WEIGHT kg/lb 14 / 30.8 14 / 30.8
CONDENSATE DRAIN SIZE mm/in 19.05 / 0.75 19.05 / 0.75
OUTDOOR UNIT
AIR FLOW l/s / CFM 614 / 1300 755 / 1600
SOUND PRESSURE LEVEL dBA 51 52
UNIT DIMENSION
HEIGHT mm/in 654 / 25.7 756 / 29.8
WIDTH mm/in 855 / 33.7 855 / 33.7
DEPTH mm/in 328 / 12.9 328 / 12.9
PACKING DIMENSION
HEIGHT mm/in 710 / 28.0 810 / 31.9
WIDTH mm/in 990 / 39.0 990 / 39.0
DEPTH mm/in 415 / 16.3 415 / 16.3
UNIT WEIGHT kg/lb 57 / 125.4 60 / 132.0
PIPE CONNECTION
TYPE FLARE VALVE FLARE VALVE
SIZE
LIQUID mm/in 6.4 / 1/4 9.52 / 3/8
GAS mm/in 15.87 / 5/8 15.87 / 5/8
REFRIGERANT CHARGE kg/lb 1.63 / 3.59 1.72 / 3.78
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m
BELOW THE UNIT.
