Acson AWM20J User Manual

64
AWM-J-2010 Outline and Dimension
OUTLINE AND DIMENSION
INDOOR UNIT
MODEL: AWM09/15J/JR, A5WM10/15J/JR
800
206
288
50123456789 Note: Dimension in mm
OUTDOOR UNIT
MODEL: ALC09/15C/CR, A5LC10/15C/CR
3
)1.0(
B
FE
NCN
KLL
M
30
)
2.
1(
A
D
19
)
7
.
0
(
C
GH
IJ
O
80
3(
.
)1
65
2(
.
)6
Dimension A B C D E F G H I J K L M N O
10 / 15C / CR
700 521 250 485 175 36 95 93 86 68 441 130 111 15 18
(27.5) (20.5) (9.8) (19.1) (6.8) (1.4) (3.7) (3.6) (3.3) (2.6) (17.3) (5.1) (4.3) (0.5) (0.7)
50123456789 Note: Dimension in mm
