Engineering & Physical Data AWM-J-2010
General Data - Heat pump (R410A)
MODEL
INDOOR UNIT A5WM10JR A5WM15JR
OUTDOOR UNIT A5LC10CR A5LC15CR
NOMINAL COOLING CAPACITY
Btu/h 9040 10750
W 2650 3150
NOMINAL HEATING CAPACITY
Btu/h 9550 11530
W 2800 3380
NOMINAL TOTAL INPUT POWER (COOLING)
W 825 1094
NOMINAL TOTAL INPUT POWER (HEATING)
W 775 988
NOMINAL RUNNING CURRENT (COOLING)
A 3.70 5.10
NOMINAL RUNNING CURRENT (HEATING)
A 3.20 4.70
POWER SOURCE
V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
EER
W/W 3.21 2.88
COP
W/W 3.61 3.42
REFRIGERANT TYPE
R410A R410A
REFRIGERANT CONTROL (EXPANSION DEVICE)
OUTDOOR CAP. TUBE OUTDOOR CAP. TUBE
INDOOR UNIT
CONTROL
AIR DISCHARGE
AUTO LOUVER (UP & DOWN) &
GRILLE (LEFT & RIGHT)
AUTO LOUVER (UP & DOWN) &
GRILLE (LEFT & RIGHT)
OPERATION LCD REMOTE CONTROL LCD REMOTE CONTROL
AIR FLOW
HIGH
l/s / CFM 158 / 335 163 / 346
MEDIUM
l/s / CFM 132 / 279 138 / 293
LOW
l/s / CFM 105 / 222 113 / 240
SOUND PRESSURE LEVEL (H/M/L)
dBA 38 / 32 / 27 38 / 34 / 29
UNIT DIMENSION
HEIGHT
mm/in 288 / 11.3 288 / 11.3
WIDTH
mm/in 800 / 31.5 800 / 31.5
DEPTH
mm/in 204 / 8.0 204 / 8.0
PACKING DIMENSION
HEIGHT
mm/in 350 / 13.8 350 / 13.8
WIDTH
mm/in 874 / 34.4 874 / 34.4
DEPTH
mm/in 280 / 11.0 280 / 11.0
UNIT WEIGHT
kg/lb 12 / 26.5 12 / 26.5
CONDENSATE DRAIN SIZE
mm/in 16 / 0.6 16 / 0.6
OUTDOOR UNIT
AIR FLOW
l/s / CFM 396 / 840 457 / 969
SOUND PRESSURE LEVEL
dBA 46 49
UNIT DIMENSION
HEIGHT
mm/in 540 / 21.3 540 / 21.3
WIDTH
mm/in 700 / 27.6 700 / 27.6
DEPTH
mm/in 250 / 9.8 250 / 9.8
PACKING DIMENSION
HEIGHT
mm/in 620 / 24.4 620 / 24.4
WIDTH
mm/in 810 / 31.9 810 / 31.9
DEPTH
mm/in 330 / 13.0 330 / 13.0
UNIT WEIGHT kg/lb 34 / 75.0 34 / 75.0
PIPE CONNECTION
TYPE
FLARE VALVE FLARE VALVE
SIZE
LIQUID
mm/in 6.4 / 1/4 6.4 / 1/4
GAS
mm/in 9.5 / 3/8 12.7 / 1/2
REFRIGERANT CHARGE
kg/lb 0.80 / 1.76 0.89 / 1.96
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
a) COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR
b) HEATING - 20°C DB INDOOR AND 7°C DB / 6°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m
BELOW THE UNIT.
