Engineering & Physical Data AWM-J-2010
Component Data - Cooling Only (R22)
MODEL
INDOOR UNIT AWM20J AWM25J
OUTDOOR UNIT ALC20C ALC25C
INDOOR FAN
TYPE CROSS FLOW FAN CROSS FLOW FAN
QUANTITY 11
MATERIAL
GLASS REINFORCED ACRYL
STYRENE RESIN
GLASS REINFORCED ACRYL
STYRENE RESIN
DRIVE DIRECT DIRECT
DIAMETER mm/in 102 / 4.02 102 / 4.02
LENGTH mm/in 867 / 34.13 867 / 34.13
INDOOR FAN MOTOR
TYPE INDUCTION INDUCTION
QUANTITY 11
INDEX OF PROTECTION (IP) IP44 IP44
OUTDOOR FAN
TYPE PROPELLER PROPELLER
QUANTITY 11
MATERIAL
GLASS REINFORCED ACRYL
STYRENE RESIN
GLASS REINFORCED ACRYL
STYRENE RESIN
DRIVE DIRECT DIRECT
DIAMETER mm/in 457.2 / 18 457.2 / 18
OUTDOOR FAN
MOTOR
TYPE INDUCTION INDUCTION
QUANTITY 11
INDEX OF PROTECTION (IP) IP54 IP54
COMPRESSOR
TYPE ROTARY HERMETIC ROTARY HERMETIC
OIL TYPE ATMOS NM56M or SUNISO 4GDID ATMOS NM56M or SUNISO 4GDID
OIL AMOUNT cm
3
/ fl .oz. 1000 / 35.2 700 / 24.6
INDOOR COIL
TUBE
MATERIAL
SEAMLESS INNER GROOVE
COPPER
SEAMLESS INNER GROOVE
COPPER
DIAMETER mm/in 7.00 / 0.276 7.00 / 0.276
THICKNESS mm/in 0.24 / 0.009 0.28 / 0.011
FIN
MATERIAL ALUMINIUM (HYDROPHILIC FIN) ALUMINIUM (HYDROPHILIC FIN)
THICKNESS mm/in 0.105 / 0.0041 0.11 / 0.004
FACE AREA m
2
/ft
2
0.29 / 3.100 0.18 / 1.930
ROW 22
FIN PER INCH 18 18
OUTDOOR COIL
TUBE
MATERIAL
SEAMLESS INNER GROOVE
COPPER
SEAMLESS INNER GROOVE
COPPER
DIAMETER mm/in 7.00 / 0.276 7.00 / 0.276
THICKNESS mm/in 0.28 / 0.011 0.28 / 0.011
FIN
MATERIAL ALUMINIUM (RAISE LANCE) ALUMINIUM (RAISE LANCE)
THICKNESS mm/in 0.11 / 0.0043 0.127 / 0.005
FACE AREA m
2
/ft
2
0.52 / 5.59 0.61 / 6.52
ROW 22
FIN PER INCH 18 18
AIR QUALITY FILTER
TYPE SARANET SARANET
QUANTITY pc 22
SIZE
LENGTH mm/in 421 / 16.57 421 / 16.57
WIDTH mm/in 306 / 12.05 306 / 12.05
THICKNESS mm/in 2 / 0.08 2 / 0.08
CASING
INDOOR UNIT
MATERIAL HIGH IMPACT POLYSTYRENE HIGH IMPACT POLYSTYRENE
FINISHING MAT MAT
COLOUR WHITE WHITE
OUTDOOR UNIT
MATERIAL GALVANISED MILD STEEL GALVANISED MILD STEEL
FINISHING POLYESTER POWDER POLYESTER POWDER
COLOUR LIGHT GREY LIGHT GREY
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
