Engineering & Physical Data AWM-J-2010
Component Data - Heat Pump (R410A)
MODEL
INDOOR UNIT A5WM10JR A5WM15JR
OUTDOOR UNIT A5LC10CR A5LC15CR
INDOOR FAN
TYPE
CROSS FLOW FAN CROSS FLOW FAN
QUANTITY
11
MATERIAL GLASS REINFORCED ACRYL
STYRENE RESIN
GLASS REINFORCED ACRYL
STYRENE RESIN
DRIVE
DIRECT DIRECT
DIAMETER
mm/in 92 / 3.6 92 / 3.6
LENGTH
mm/in 607 / 23.9 607 / 23.9
INDOOR FAN MOTOR
TYPE
INDUCTION INDUCTION
QUANTITY
11
INDEX OF PROTECTION (IP)
IP44 IP44
OUTDOOR FAN
TYPE
PROPELLER PROPELLER
QUANTITY
11
MATERIAL GLASS REINFORCED ACRYL
STYRENE RESIN
GLASS REINFORCED ACRYL
STYRENE RESIN
DRIVE
DIRECT DIRECT
DIAMETER
mm/in 406 / 16 406 / 16
OUTDOOR FAN
MOTOR
TYPE
INDUCTION INDUCTION
QUANTITY
11
INDEX OF PROTECTION (IP)
IP24 IP24
COMPRESSOR
TYPE
ROTARY ROTARY
OIL TYPE
RB68A or FREOL ALPHA68M RB68A or FREOL ALPHA68M
OIL AMOUNT
cm
3
/ fl .oz. 350 / 12.3 430 / 15.1
INDOOR COIL
TUBE
MATERIAL SEAMLESS INNER GROOVE
COPPER
SEAMLESS INNER GROOVE
COPPER
DIAMETER
mm/in 7.00 / 0.276 7.00 / 0.276
THICKNESS
mm/in 0.28 / 0.011 0.28 / 0.011
FIN
MATERIAL
ALUMINIUM (HYDROPHILIC FIN) ALUMINIUM (HYDROPHILIC FIN)
THICKNESS
mm/in 0.11 / 0.004 0.11 / 0.004
FACE AREA
m
2
/ft
2
0.18 / 1.930 0.18 / 1.930
ROW
22
FIN PER INCH
18 18
OUTDOOR COIL
TUBE
MATERIAL SEAMLESS INNER GROOVE
COPPER
SEAMLESS INNER GROOVE
COPPER
DIAMETER
mm/in 7.00 / 0.276 9.52 / 3/8
THICKNESS
mm/in 0.28 / 0.011 0.33 / 0.013
FIN
MATERIAL
ALUMINIUM (RAISE LANCE) ALUMINIUM (HYDROPHILIC FIN)
THICKNESS
mm/in 0.10 / 0.004 0.11 / 0.004
FACE AREA
m
2
/ft
2
0.36 / 3.940 0.36 / 3.940
ROW
11
FIN PER INCH
20 18
AIR QUALITY FILTER
TYPE
MILDEW PROOF PP FILTER MILDEW PROOF PP FILTER
QUANTITY
pc 22
SIZE
LENGTH
mm/in 302 / 11.9 302 / 11.9
WIDTH
mm/in 280 / 11.0 280 / 11.0
THICKNESS
mm/in 2.0 / 0.1 2.0 / 0.1
CASING
INDOOR UNIT
MATERIAL HIGH IMPACT POLYSTYRENE HIGH IMPACT POLYSTYRENE
FINISHING MAT MAT
COLOUR WHITE WHITE
OUTDOOR UNIT
MATERIAL GALVANISED MILD STEEL GALVANISED MILD STEEL
FINISHING POLYESTER POWDER POLYESTER POWDER
COLOUR LIGHT GREY LIGHT GREY
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
