AWM-J-2010 Electrical Data
Electrical Data
Electrical Data - Cooling Only (R22)
MODEL
INDOOR UNIT AWM09J AWM15J
OUTDOOR UNIT ALC09C ALC15C
INDOOR MOTOR
INSULATION GRADE CLASS E CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1/ 50 220 - 240 / 1/ 50
RATED INPUT POWER W 31 40
RATED RUNNING CURRENT A 0.18 0.20
MOTOR OUTPUT W 18 18
POLES 44
OUTDOOR MOTOR
INSULATION GRADE CLASS B CLASS B
POWER SOURCE V/Ph/Hz 220 - 240 / 1/ 50 220 - 240 / 1/ 50
RATED INPUT POWER W 45 59
RATED RUNNING CURRENT A 0.20 0.26
MOTOR OUTPUT W 18 24
POLES 66
COMPRESSOR
INSULATION GRADE CLASS E CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1/ 50 220 - 240 / 1/ 50
CAPACITOR μF 30.0 30.0
RATED INPUT POWER W 849 1077
RATED RUNNING CURRENT A 3.70 4.90
LOCKED ROTOR AMP. A 20 23
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
Electrical Data - Heat Pump (R22)
MODEL
INDOOR UNIT AWM09JR AWM15JR
OUTDOOR UNIT ALC09CR ALC15CR
INDOOR MOTOR
INSULATION GRADE CLASS E CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1/ 50 220 - 240 / 1/ 50
RATED INPUT POWER W 31 40
RATED RUNNING CURRENT A 0.18 0.20
MOTOR OUTPUT W 18 18
POLES 44
OUTDOOR MOTOR
INSULATION GRADE CLASS B CLASS B
POWER SOURCE V/Ph/Hz 220 - 240 / 1/ 50 220 - 240 / 1/ 50
RATED INPUT POWER W 45 59
RATED RUNNING CURRENT A 0.20 0.26
MOTOR OUTPUT W 18 24
POLES 66
COMPRESSOR
INSULATION GRADE CLASS E CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1/ 50 220 - 240 / 1/ 50
CAPACITOR μF 30.0 30.0
RATED INPUT POWER (COOLING) W 849 1093
RATED INPUT POWER (HEATING) W 674 967
RATED RUNNING CURRENT (COOLING) A 3.70 5.00
RATED RUNNING CURRENT (HEATING) A 3.00 4.50
LOCKED ROTOR AMP. A 20 23
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
