Electrical Data AWM-J-2010
Electrical Data - Cooling Only (R22)
MODEL
INDOOR UNIT AWM20J AWM25J
OUTDOOR UNIT ALC20C ALC25C
INDOOR MOTOR
INSULATION GRADE CLASS E CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
RATED INPUT POWER W 60 72
RATED RUNNING CURRENT A 0.27 0.34
MOTOR OUTPUT W 26 30
POLES 44
OUTDOOR MOTOR
INSULATION GRADE CLASS B CLASS B
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
RATED INPUT POWER W 120 124
RATED RUNNING CURRENT A 0.53 0.54
MOTOR OUTPUT W 64 75
POLES 66
COMPRESSOR
INSULATION GRADE CLASS E CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
CAPACITOR μF 60.0 50.0
RATED INPUT POWER W 1674 2334
RATED RUNNING CURRENT A 7.41 10.41
LOCKED ROTOR AMP. A 32 54
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
Electrical Data - Heat Pump (R22)
MODEL
INDOOR UNIT AWM20JR AWM25JR
OUTDOOR UNIT ALC20CR ALC25CR
INDOOR MOTOR
INSULATION GRADE CLASS E CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
RATED INPUT POWER W 60 72
RATED RUNNING CURRENT A 0.27 0.34
MOTOR OUTPUT W 26 30
POLES 44
OUTDOOR MOTOR
INSULATION GRADE CLASS B CLASS B
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
RATED INPUT POWER W 120 124
RATED RUNNING CURRENT A 0.53 0.54
MOTOR OUTPUT W 75 75
POLES 66
COMPRESSOR
INSULATION GRADE CLASS E CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
CAPACITOR μF 60.0 50.0
RATED INPUT POWER (COOLING) W 1674 2334
RATED INPUT POWER (HEATING) W 1574 2269
RATED RUNNING CURRENT (COOLING) A 7.41 10.41
RATED RUNNING CURRENT (HEATING) A 6.93 10.13
LOCKED ROTOR AMP. A 32 54
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
