AWM-J-2010 Performance Data
(b) Indoor Condition: 25°C DB, 16°C WB
Outdoor Condition: 40°C DB
Indoor DB˚C Indoor WB˚C
Outdoor DB, ˚C
40
TC (kW) SHC (kW) PI (kW)
16
24
10.42 10.23
4.36
25
...........................................
x
2
y
2
z
2
27 10.66 10.66 4.38
Total capacity, TC
Interpolation Method:
⇒
25º C – 24º C
=
x
2
– 10.42kW
27º C – 24º C 11.66kW – 10.42kW
⇒ x
1
= 10.50kW
Sensible capacity, SHC
Interpolation Method:
⇒
25º C – 24º C
=
y
2
– 10.23kW
27º C – 24º C 10.66kW – 10.23kW
⇒ y
2
= 10.37kW
Power Input, PI
Interpolation Method:
⇒
25º C – 24º C
=
z
2
– 4.36kW
27º C – 24º C 4.38kW – 4.36kW
⇒ z
2
= 4.37kW
* Repeat process (a) and (b) in 1
st
step for the condition below:
(c) Indoor Condition: 25°C DB, 19°C WB
Outdoor Condition: 35°C DB
⇒ x
3
= 11.65kW
⇒ y
3
= 8.94kW
⇒ z
3
= 4.08kW
(d) Indoor Condition: 25°C DB, 19°C WB
Outdoor Condition: 40°C DB
⇒ x
4
= 11.36kW
⇒ y
4
= 9.03kW
⇒ z
4
= 4.43kW
