USER MANUAL 750000992/16
6-3
MTS
e
OTS Test SET-UP
mode is selected, the output power is calibrated (CAL).
In the "Emul. OLS» mode the signal is alternated every 4 s.
in order to be compatible with the TwinTest mode of the
OLS and OFI Acterna series.
Power Mode only available with laser sources.
Choice of the output power of the laser source:
CAL: Output power calibrated at 1 mW i.e 0 dBm.
VAR: Variable power from 0 to - 10 dBm.
Note The Power option is only available if the continuous signal (CW)
mode has been selected and the Scanning mode is NOT selected. If
this is not true the output power is calibrated by default.
Unit Choice of the transmitted power unit: W or dBm.
Selecting Power meter parameters
You can choose the following Power meter parameters from the Power meter
menu of the OTS Test Setup window
1
:
Wavelength Selection from: Auto, 850nm, 1310nm, 1550nm or User.
(Selecting the User wavelength allows you to select the
exact wavelength you require with the User Select menu
option described below).
User Select Selection of the any wavelength value between 800 nm to
1650 nm in 1 nm steps, using the arrow key <- or ->.
Note The User Select menu option is only available if User has been
selected from the Wavelength menu option.
Range The measurement range of the power meter: Auto, mW, µW
or nW. If Auto is selected the optimal range is chosen for
the Power meter acquisition.
Mode Selection of the measurement result storage method: None,
Autostore orAutoprint.
None: No measurement results are stored.
Autostore: The autostore mode automatically stores the
measurement results to a file at the time interval selected
with the Auto Time function described below. Refer to
"Manipulating stored data" on page 8-16 for the description
of the file storage function.
Autoprint: The autoprint mode automatically send
measurement results to a printer connected to the
1. During storage and printing operations none of the menu options apart from
the Unit and Alarm Threshold can be modified.
