8-8
USER MANUAL 750000992/16
File management MTS
e
OTS Module Semi- Automatic Filenaming
When you store an OTS data to disk using semi-automatic file naming, the file
name is created using the file naming conventions selected by the user as
follows:
• Move the cursor on the Filename line.
• Press the <Edit> key. The Editing menu appears.
On the Coding line of the editing menu, define the filename code. For that,
move the cursor on the different line of the menu (in the order you wish for
the coding) and enter the corresponding characters pressing the <Valid
Char.> key.
• On the Title line, enter as much «t» as you want of characters of the title in the
filename.
• On the Cabl. Ident., Origin and Extremity lines enter as «c», «o» or «e» as you
want of characters of the concerned identification in the filename.
• On the Fiber Number line, the 2 ff are imperative for the fiber number is
always coded on two characters (see table below). If, after the coding, a f is
remove in the coding, only the last figure of the fiber number will be in the
filename.
• To code Direction, Lambda, Pulse and Resolution only one character is
necessary: see the following table.
• The semi-automatic coding can also include fixed characters, different from
coding parameter characters and selected, as in MANUAL file naming, in the
list located on the 3 last lines of the editing menu.
r
Range
MmW manual range
UµW manual range
N nW manual range
AAuto range
s
Direction
O origin to extremity
E extremity to origin
* the available values are depending on the module used.
OTS module semi-automatic file naming
t ...
First characters of the title
c ...
First characters of the cable identification
defined in the File windows
OTS module automatic file naming:
cccffwps
