USER MANUAL 750000992/16
8-7
MTS
e
Filename
OTS Module Automatic Filenaming
When you store an OTS data to disk using automatic file naming, the file name is
automatically created using the following file naming conventions :
r
Resolution *
0 4 cm
1 8 cm
2 16 cm
3 32 cm
4 64 cm
5 125 cm
6 250 cm
7 5 m
8 10 m
9 20 m
10 40 m
A 80 m
B 160 m
D 320 m
* the available values are depending on the module used.
OTS module automatic file naming:
cccffwps
ccc
First characters of the cable identification
defined in the File windows
ff
0 to 99
A0 to YZ
Fiber number
decimal coding
alphanumeric coding (100 to 999)
w
Laser wavelength used for the measurement
*
31310 nm
5 1550 nm
8850 nm
AAUTO
UUSER
OTDR module semi-automatic file naming
