8-6
USER MANUAL 750000992/16
File management MTS
e
Attention when you leave the semi-automatic mode for another mode, the cod-
ing is lost.
OTDR module semi-automatic file naming
t...
First characters of the title
c ...
First characters of the cable identification
defined in the File windows
ff 0 to 99
A0 to YZ
Fiber number
decimal coding
alphanumeric coding (100 to 999)
o ...
First characters of the origin location
e ... First characters of the extremity location
d
Direction
O origin to extremity
E extremity to origin
w
Laser wavelength used for the measurement
*
31310 nm
51550 nm
61625 nm
8850 nm
9 1300 nm
p
Pulse *
A 3 ns
B 5 ns
C 10 ns
D 20 ns
E 30 ns
F 100 ns
G 200 ns
H 300 ns
I 500 ns
J 1 µs
K 3 µs
L 10 µs
M 20 µs
