Acterna MTSe 5000 Series - Remote Control (cont.); Commands Relative to Module and Function; Commands Relative to the Keys

9-8
USER MANUAL 750000992/16
Remote control MTS
e
Commands relative to the module and the function
Format des commandes
Description des fonctions
• Module functions
OTDR Reflectometer
SOUR Source
PWM Power meter
VFL Visual fault locator
TSET Talk set
OSA Optical Spectrum Analyser (WDM)
• Module on or off
ON Module On
OFF Module Off
• Position of the module in the instrument
LEFT, RIGHt: position of the module in the instrument
(seen from the rear of the MTS
e
).
Commands relative to the keys
Format des commandes
Description des fonctions
STARt Starts /stops an acquisition.
FILE Calls up the file storage and management menu.
RESult Calls up the results screen for all measurement analysis
operations.
SETup Calls up the set-up menus.
HELP Calls up the on-line help pages.
UP, DOWN, LEFT, RIGHt: directional arrows ↑ , ↓ , ← , →.
HOMe re-displays the trace with no shift or zoom.
MODule FONction?
FONction
[LEFT, RIGHt], [OTDR, SOUR, PWM, VFL, TSET, OSA]
[LEFT, RIGHt], [OTDR, SOUR, PWM, VFL, TSET, OSA], [ON, OFF]
NAME?
[LEFT, RIGHt]
KEY
[STARt, FILE, RESult, SETup, HELP, UP, DOWN, LEFT, RIGHt, HOMe, PREView, SK1,
