Acterna MTSe 5000 Series - MTSe Command Relative to the OTDR Module (cont.); Result Commands

USER MANUAL 750000992/16
9-13
MTS
e
Command relative to the OTDR module
Result commands
Format des commandes
Description des fonctions
DSPLice Splice threshold between 0 and 601 in hundredth of dB:
0: all splices displayed;
601: no splice displayed
Factory default value: ALL
DREFlectance Reflectance threshold in dB, between -11 and -99.
- 100: all reflectances displayed.
- 10: no reflectances displayed.
Factory default value: ALL
DSLope Slope threshold in thousandth of dB/km between 0 and 2001:
0: every slope displayed
001: no slope displayed
100: slopes > 0.1 dB displayed
Factory default value: >0.10 dB/km
DGHOst Choose from yes or no to display ghost information. If ghosts are
displayed: the reflection icon is shown dotted in the result table,
the reflection value is shown between parentheses on the trace;
MEASure
MSLope
DSPLice
DREFlectance
DSLope
[TWOpoints, LINear]
[0 : 601]
[-100 : -10]
DGHOst
[YES, NO]
DREMarks
DCURve
[NO, UNCertainty, NOTes, YES
*
]
*. NOTes and YES are equivalent
[YES, NO, GRAPhic]
[0:2001]
ENDFiber
[2:15] End of fiber 2= automatic
3 to 15 = threshold in
LCABle
[0,3] Launch cable0= not valid
1 to 3 = marker 1 to 3
