9-14
USER MANUAL 750000992/16
Remote control MTS
e
e.g. “(R:-50dB)”.
Factory default value: yes.
Ghosts are only detected during an automatic measurement.
MSLope Slope measurement methods: least squares (LSA) or 2-point loss.
Factory default value: LSA
DCURve Measurements displayed on trace:
No: the trace only
YES: the trace with results and markers
GRAPhic: the trace with markers only.
Factory default value: YES
DREMarks display of notes in the table
NO: no additional display
YES and NOTes: display notes entered by the user
UNCertainty: display notes entered by the user and confidence
indicators for the result measurements.
Factory default value: No
ENDFiber Fiber end threshold from 2 to 15.
2= automatic (factory default option)
3 to 15 = threshold in dB
In most cases the AUTO option is advised.
LCABle Choose to display in the event table, the results referenced to the
launch cable.
- 0: all the results are displayed and the reference is the origin of
the fiber.
- 1, 2 or 3: results are referenced from the marker 1, 2 or 3 selected.
This marker is considered as the «end of launch cable» and is the
reference for loss and distance measurements.
Factory default value: No.
