USER MANUAL 750000992/16
9-19
MTS
e
Commands relative to the OTS modules
Conversion from delay to distance
To convert the result from second to meter, use the following formula:
with: c = speed of light in vacuum (2.99792458 m/s)
n = refractive index of the fiber
t = time (expressed in second) to convert in distance
Commands relative to the OTS modules
Power meter set-up
Format des commandes
Description des fonctions
LAMbda Wavelength for the measurement
LUser Selection of any wavelength value between 800 nm to 1650 nm (if
LAMbda = USER)
RANGe Measurement range of the power meter: Auto, mW, µW or nW.
MODe NONE: no automatic storage, neither automatic printing of the
results.
STORE: automatic storage of the results in a file at the time
interval selected in seconds in the second parameter.
D
mete rs()
ct×
2n×
-------
10
8
time
s()
×∼=
PWMeter
LUSer
RANGe
MODe
REALtime
[AUTO, MW, UW, NW] auto and manual range
[NONE, STORE, PRINT], [1:43200]time in seconds
[YES, NO]
LAMBda
[AUTO, L850, L1310, L1550, USER]
[800: 1650] valid if LAMbda= user
ALArm
AT Tenu a
REFeren
ZERo
[0:30]
[OFF, ON], [-70:30]
