Acterna MTSe 5000 Series - Power Supply and Batteries

11-2
USER MANUAL 750000992/16
Technical specifications MTS
e
Input/Output
• RS232C
• Ethernet (option)
• Centronics
• IEEE-488 GPIB (option), for MTS 5200
e
only.
Internal printer (optional for MTS 5200
e
only)
• Reference 5200/PR
• High quality (graphical) thermic printer
• 832 dots / line
• paper width: 112 mm.
Power supply
Batteries
• Up to 2 Nickel Metal Hydrid batteries
• Battery autonomy at 25° C (for 1 battery):
- up to 8 hours of standard use, with normal backlight, according to Bellcore
/ Telecordia GR-196-CORE standard.
- up to 3 hours with permanent acquisition, with normal backlight
- up to 2.5 hours with permanent acquisition, with high backlight
AC/DC Adapter / Charger
MTS 5100
e
MTS 5200
e
Reference 5003AC/DC adapter / charger 5007AC/DC adapter / charger
Input 100-250 V
50-60 Hz
1.6 A
85-264 V
47-400 Hz
1.3 A
Output 12 V DC
4.2 A
12 V DC
55 Watt max.
Compliant CE CE
