USER MANUAL 750000992/16
11-3
MTS
e
Mainframe specifications
Dimensions
Dimensions of the external keyboard (optional): 280 x 130 x 25 mm
(11 x 5.1 x 1 inch).
Environmental conditions
Vibration
The MTS
e
is able to withstand the following vibration tests:
• Complete test consists of 6 cycles for each of the 3 axes x, y, z.
• One cycle sweeps from 5 Hz to 200 Hz and back down to 5 Hz with a sweep
duration of one minute per octave.
• 3 mm amplitude displacement test for the range of 5 Hz to 9 Hz.
• 1G acceleration test for the range of 10 Hz to 200 Hz.
Temperature range
• Operating on mains, options not included: -20° C to + 50° C
(- 4°C to + 122°F)
• Operating, specifications guaranteed, all options included:
0° C to +40° C (+ 32°F to + 104°F)
• Storage: -20° C up to + 60° C (- 4°F up to + 140°F)
Humidity
• 95% without condensing
EMI/ESD
• CE compliant
Base unit MTS 5100
e
MTS 5200
e
Height 90 mm 130 mm
Width 235 mm 235 mm
Depth 300 mm 300 mm
Weight 3.5 kg
including 1 module & 1 battery
5.5 kg
including internal printer, 2 modules
& 1 battery
