USER MANUAL 750000992/16
11-15
MTS
e
Specifications of the OTS modules at 25 °C
Specifications of the OTS modules at 25 °C
Light sources
Possibility of alternated transmission at 1310/1550 nm (Laser source) or 850/
1300 nm (LED source), every 10 seconds approx.
Multiple Wavelength Power Meter
Calibrated wavelengths: 850 / 1310 / 1550 nm
Possible wavelengths: 800 to 1650 nm in 1 nm increments
Accuracy for calibrated wavelengths: ± 0,2 dB (at - 30 dBm, FC/PC)
Resolution: 0,01 dBm / 0,01 nW
Measurement range: + 5 to - 65 dBm (at 850 nm)
+ 5 to - 70 dBm (at 1310 and 1550 nm)
Possibility of alternated measurement at 1310 and 1550 nm.
Power Meter memory
• Capacity: 300 results
• Stored parameters for manual or automatic measurement:
- Date / time
- Wavelength
- Measurement result (dBm)
- Reference (dBm)
- Received mode (CW, 270 Hz ... 2 kHz)
Specifications of the Talkset option (OTS module)
• Dynamic: 35 dB typical at 25°C
Laser sources LED sources
Wavelength
(source at 25°C)
1310 & 1550
± 30 nm
850 nm
± 30 nm
1300 nm ±
30 nm
850 & 1300 nm
± 30 nm
Spectral width < 5 nm 50 nm 150 nm 50 / 150 nm
Stability in 1 hour
Stability in 24 h.
± 0,05 dB
± 0,15 dB
Calibrated output
power
0 dBm -17 dBm -19 dBm -18 / -20 dBm
Variable output
power
0 to - 10 dBm
Modulation of
transmitted signal
270 Hz, 330 Hz, 1 kHz and 2 kHz
