Technical specifications MTS
e
Specifications WDM modules
Typical values measured at 25° C, unless otherwise stated.
Module 5071- C band Module 5073- C+L band
Wavelength
Range 1525-1570 nm 1525-1610 nm
Sweep time (real time) < 1 s <1,5 s
Accuracy
a
a. from -40 dBm to +5 dBm.
± 10 pm
Display Resolution 1 pm
Min. spacing between
channels
10 GHz (80 pm)
Optical Bandwidth (FWHM) 35 pm
Power levels
Display range - 90 dBm at + 30 dBm
Display Resolution 0,01 dB
Measurement range on a
channel
- 70 dBm at + 10 dBm
Max. admissible power:
- total
(before signal cut off)
- for a channel
+ 20 dBm
+ 10 dBm
Accuracy
b
b. at -30 dBm and 1550 nm, excluding the uncertainty due to the input connector.
± 0,5 dB max
Linearity
1
±0,1 dB
Flatness
± 0,2 dB
c
c. at -30 dBm and in the range 1530 nm - 1565 nm (reference : 1550 nm)
± 0,2 dB
d
d. at -30 dBm and in the range 1530 nm - 1605 nm (reference : 1550 nm)
Polarization dependence
(PDL)
± 0,2 dB
ORL
(Optical Return Loss) > 35 dB
ORR
(Optical Rejection Ratio)
e
-
e. from the top of a carrier, in the range 1530 to 1605 nm and at 0 dBm
40 dB at 0,8 nm from the carrier
34 dB at 0,4 nm from the carrier
