Range Range used for the measurement
Resolution Space between measurement points
Averaging Number of seconds of averaging for the measurement
Fiber Number Fiber number
Fiber parameters
Index Index of the fiber
Scatter Coeff. Back scattering coefficient of the fiber
Result parameters
Splice Threshold Threshold for splice display.
Reflec. Threshold Threshold for reflective event display.
Slope Threshold Threshold used to display the slope.
Display Ghosts Selection of ghost display.
Fiber End Threshold Threshold used to detect the end of the fiber.
Launch cable Location of the end of launch cable (see page 5-4)
Table 2: Example of header for WDM results
Instrument parameters
MTS 5200
e
, 865,
3.22
Instrument used for the acquisition, serial number,
software version.
Module:
5071 WDM, 280,
Identification of the module
(type, serial number).
File parameters
Trace Filename of the trace if it has been loaded from memory
storage device.
Title Title of the trace
Operator Operator name
Cable Id. Identification name for the cable
Origin Name entered for the origin of the fiber
End Name entered for the end of the fiber
Test point Identification name for the test point
Fiber number
Comments
Acquisition parameters
Measurement Date Date and time the measurement was made
Laser Wavelength of the laser used to make the measurement
Table 1: Example of header for OTDR results
