USER MANUAL 750000992/16
4-11
MTS
e
Rear panel
IEEE port
Optional, for MTS 5200
e
mainframe only: 24 pin parallel port allowing the
connection to a controller.
Reference of the option: 5200/IEEE.
Computer display output
Optional, for MTS 5200
e
mainframe with color TFT display only: 15 pin port
allowing the connection to a projector or a monitor.
Reference of the option: 5200/VGA
When a monitor or a projector is connected, press the key <VGA> in the menu
SET-UP / System Setup to switch to the VGA display.
