Hardware Manual
24
b. Insert the sealing insert into the conduit gland body and then attach the clamping nut as
tightly as possible to complete the cable solution.
8. If only the network cable will be connected, connect the network cable to the Ethernet port
of the camera at this point. Then, proceed with Step 4: Install the Camera to the Surface on
page 26.
9. If connecting other cables, attach the terminal blocks to the cables. See Other Connections
on page 28.
