Quick Installation Guide 3
REAR PANEL
1 2 3 4 5 6
7 8
9
1
Ground Screw
2
Power Connector
3
Power Source Switch
5
Audio Line In
6
Audio Out
7
Power Over Ethernet Ports
8
Terminal Block Connector
9
Antenna Connectors
(optional)
FRONT PANEL
1
USB Ports *
6
Hard Disk Activity LED
7
Power Button
8
GPS Antenna Connector
9
Hard Disk Bay
10
Reset Button
11
I/O Ports
1 2 3 4 5 6 7
9
11
8
10
AT A GLANCE
2
MNR-320P: USB 2.0 x 3, USB 3.0 x 1
MNR-330P: USB 2.0 x2, USB 3.0 x2
2
HDMI Port
3
VGA Port
4
LAN Ports
5
Power LED
4
Audio Mic In
P: Standard power outlet source
V: Vehicle power source
