S002217-2 Basketball System
Assembly Instructions (cont)
Step 6
WARNING: You must follow this step otherwise
you will not be able to assemble the unit.
Insert the top Pole 6 into the upper Middle Pole 5
so that it protrudes out at the top.
Ensure that this step is complete before
moving to the next step.
Step 5
Attach the Bracket N to the
bolts that are visible behind the
Backboard 1 from Step 4, use
Washer E and Nut B to fix in place.
Attach the other ends of the
Support Arms 10 and attach them
to the holes provided in the middle
of the Backboard 1 using Bolt F
and Washer C. Ensure that the
straight end of Support Arm 10 is
attached to the Backboard 1 not
the angled end.
Do not secure the bottom of
Support Arm 10 until Step 8.
F
F
C C
B
B
B
B
E
E
E
E
1
10
10
5
6
6
5
6
5
