Actreg ASR-80 User Manual

PNEUMATIC ACTUATORS
ASSEMBLY & MAINTENANCE PROCEDURES
Ref. Doc. MMMACTREGDRE English Rev.2 – January 2012
7
ACTREG Actuators sizes 500 & larger
ACTREG S.A. states that Actreg Actuators covered by this Certificate have been designed and
manufactured in accordance with the following European Directives requirements:
- European Pressure Equipment Directive 97/23/CE: classified according to Category I, Module A
Evaluation Procedure of Conformity mod. A certified by the manufacturer ACTREG.
Marking CE.
- Machines Directive 89/392/CEE.
- Directive 94/9/CE ATEX, classification Group II, Cat. 2 for use in explosive atmospheres, Zones
1,2 & 21,22. Conformity evaluation according to Appendix VIII.
Marking CE Ex II2GDc.
-EN 15714-3 Pneumatic Part-Turn Actuators For Industrial Valves
Applied harmonized and non-harmonized technical Standards:
- EN 13463-1:2001, EN 1127-1.
The electrical and mechanical accessories are not covered by this statement and will have to
carry their own certificate in order to be assembled with Actreg actuators.
The suitability of the materials and design of the actuator type in terms of its working conditions
are the responsibility of the actuator’s end user.
ADA & ASR SIZES
DESCRIPTION OF THE PRESSURE EQUIPMENTS
Type Serie Size PN
10
PN-10
20
40
80
130
200
ADA
Double
Acting
300
500
850
1200
1750
2100
2500
ASR
Spring
Return
4000
PN-8
