Setup > Controller
Overview
Setup station and network settings
1. CONTROLLER NAME gives the
station a unique name. Press the
text box to access keyboard
2. ROOM defines the single space
that accommodates the connected
devices. Up to 8 individual rooms
can be setup to be stand alone and
also joined (room linking)
3. NETWORK ID is the local area Fresco
network. This value should not be
changed
4. CONTROLLER ID
5. BAUD RATE is the data transfer rate.
This should not be changed
6. NETWORK settings are used when
accessing the station from an IP
network
7. IP ADDRESS/SUBNET MASK values
can be modified based on IP
network configuration
8. DEFAULTS sends all network settings
back to factory default
