DMX RGB CONTROL
Overview
Control color intensity, hue, and saturation for DMX controlled RGB fixtures
1. Raise or lower overall intensity for
the lighting zone
2. RGB values are displayed as colors
change. Input specific values be
pressing any of the RGB value fields
3. Change overall color (hue) by
pressing anyway in the color field
4. Change color saturation by touching
anywhere in the large color box
