nLight ECLYPSE Enclosure
SURFACE MOUNT ENCLOSURE WITH SCREW COVER
TO REMOVE RELAY PANEL COVER:
1) UNFASTEN FOUR PHILLIPS SCREWS AT CORNERS OF COVER
2) REMOVE COVER FROM RIGHT EDGE AND ENGAGEMENT FEATURES ON LEFT SIDE WILL RELEASE
TO INSTALL THE PANEL COVER:
1) HOOK IN THE ENGAGEMENT FEATURES ON THE LEFT FROM THE OUTSIDE
2) FASTEN THE FOUR PHILLIPS SCREWS AT THE CORNERS OF THE COVER
Note: If cover hardware is misplaced, utilize screws and lockwashers with paint-piercing features. Enclosure
utilizes "SEMS" and "KEPS" fasteners with integrated toothed lock washers for paint piercing to ensure proper
bonding of painted enclosure parts.
ENCLOSURE UNTILIZES "SEMS" AND "KEPS" FASTENERS:
INTEGRATED TOOTHED LOCK WASHERS FOR PAINT
PIERCING TO ENSURE PROPER BONDING OF PAINTED
ENCLOSURE PARTS.
