Torque the spark plug. (If you do
not have a torque wrench, tighten
the spark plug two-thirds of a turn
after it contacts the cylinder head.)
Tightening torque:
Use a wrench to remove the bolt
holding the ignition coil. Pull the
ignition coil up slightly.
Disconnect the wire connector
from the ignition coil by pushing
on the lock tab and pulling on the
connector. Pull on the plastic
connector, not the wires.
Put the new spark plug into the
socket; then screw it into the hole.
Screw it in by hand so you do not
crossthread it.
Remove the spark plug with
a five-eighths inch (16 mm) spark
plug socket.
Remove the ignition coil.
6.
5.
4.
3.
7.
8.
CONTINUED
Spark Plugs
Maintenance
225
CCOONNNNEECCTTOORR
IIGGNNIITTIIOONN
CCOOIILL
LLOOCCKK TTAABB
13 lbf·ft (18 N·m , 1.8 kgf·m)
To Next Page
