Remove the electrical connector
from the bulb by pulling the
connector straight back.
Remove the rubber weather seal
by pulling on the tab.
Unclip the end of the hold-down
wire from its slot. Pivot it out of
the way and remove the bulb.
Insert the new bulb into the hole,
making sure the tabs are in their
slots. Pivot the hold-down wire
back in place and clip the end into
the slot.
Install the rubber seal over the
back of the headlight assembly.
Make sure it is right side up; it is
marked ‘‘TOP.’’
Push the electrical connector onto
the tabs of the new bulb. Make
sure it locks in place.
Turn on the headlights to test the
new bulb.
(Passenger’s side)
Install the power steering
reservoir on the bracket.
3.
4.
5.
6.
7.
8.
9.
Lights
Maintenance
245
HHOOLLDD
DDOOWWNN WWIIRREE
BBUULLBB
WWEEAATTHHEERR
SSEEAALL
CCOONNNNEECCTTOORR
