Moves the whole seat
up and forward, or
down and backward.
Thefrontoftheseat
also tilts up or down at
thesametime.
The controls for the power
adjustable front seats are on the
outside edge of each seat bottom.
You can adjust the seats with the
ignition switch in any position. Make
all seat adjustments before you start
driving.
Moving the long horizontal switch
adjusts the seat bottom in several
directions. The seat bottom adjusts
in the direction you move the switch.
The short vertical switch adjusts the
seat back angle.
Moves the seat
forward and backward.
Moves the front of the
seat up or down.
Raises or lowers the
seat.
Adjusts the seat-back
angle forward or
backward.
See pages for important safety
information and warnings about how to
properly position seats and seat-backs.
Driver’s seat only:
Driver’s seat only:
12 14
Driver’s seat only:
Seats
Power Seat Adjustment
138
