Open the hood. To change a bulb
on the driver’s side, undo the
three fasteners and remove the air
intake cover.
Remove the electrical connector
from the bulb by pulling the
connector straight back.
Remove the rubber weather seal
by pulling on the tab.
Unclip the end of the hold-down
wire from its slot. Pivot it out of
the way, and remove the bulb
socket.
Pull the burned out bulb straight
out of its socket.
Push the new bulb straight into
the socket until it bottoms.
1. 2.
3.
4.
5.
CONTINUED
Lights
Maintenance
303
FASTENER
AIR INTAKE COVER
HOLD-DOWN WIRE
BULB
CONNECTOR
RUBBER WEATHER SEAL
SOCKET
