Pull out the small latch plate and the
latch plate from each holding slot in
the ceiling, and pull out the seat belt
to extend it.
Pull out the outer shoulder belts
from the hook. Both of the third-row
hooks should only be used when the
seat belt is detached.
Line up the triangle marks on the
small latch plate and anchor buckle
when reattaching the belt and
buckle.
Tug on the seat belt to verify that the
detachable anchor is securely
latched. Make sure the seat belt is
not twisted.
SECOND ROW CENTER SEAT
LATCH PLATE
SMALL LATCH PLATE
THIRD ROW SEATS
HOOK
SMALL LATCH PLATE
ANCHOR BUCKLE
TRIANGLE
MARKS
Seats
147
