3. Remove the blade from its holder
by grabbing the tabbed end of the
blade. Pull firmly until the tabs
come out of the holder.
4. Examine the new wiper blades. If
they have no plastic or metal
reinforcement along the back
edge, remove the metal
reinforcement strips from the old
wiper blade, and install them in the
slots along the edge of the new
blade.
5. Slide the new wiper blade into the
holder until the tabs lock.
6. Slide the wiper blade assembly
onto the wiper arm. Make sure it
locks in place.
7. Lower the wiper arm against the
window.
Windshield: Lower the passenger's
side first, then the driver's side.
BLADE
BLADE
REINFORCEMENT
Wiper Blades
412
08/06/06 16:58:07 09 ACURA MDX MMC North America Owner's M 50 31STX620 enu
