uuReplacing Light BulbsuBack-Up Light
Maintenance
Back-Up Light
When replacing, use the following bulbs.
1. Remove the cover by prying on the edge
using a flat-tip screwdriver.
u Wrap the flat-tip screwdriver with a cloth
to prevent scratches.
2. Turn the socket to the left and remove it.
Remove the old bulb.
3. Insert a new bulb.
Back-Up Light: 21 W
Bulb
Socket
