To achieve a proper tongue load,
start by loading 60 percent of the
load toward the front of the trailer
and 40 percent toward the rear, then
re-adjust the load as needed.
The maximum allowable weight of
the vehicle, all occupants, all cargo,
and the tongue is:
The best way to confirm that vehicle
and trailer weights are within limits
is to have them checked at a public
scale.
Using a suitable scale or a special
tongue load gauge, check the tongue
load the first time you set up a
towing combination (a fully-loaded
vehicle and trailer), then recheck the
tongue load whenever the conditions
change.
The maximum allowable weight of
the vehicle axles is:
on the front axle
on the rear axle
Gross Vehicle Weight Rating
(GVWR):
Checking LoadsGross Axle Weight Rating
(GAWR):
Towing a Trailer
184
4,300 Ibs (1,950 kg)
2,335 Ibs (1,060 kg)
2,030 Ibs (920 kg)
